You’ve developed the most fancy application and are running it on your Synology in a Docker container.

But you really don’t want that ugly “Not secure” when opening it. This series goes over your options, starting with the easiest one to setup: using the Synology nginx.

Open Synology DSM and

Step 1: Setup Reverse Proxy

Control Panel > Login Portal > Advanced > Reverse Proxy > Create

Reverse Proxy Rules:

• Pick a “Reverse Proxy Name”
• Source
  • Protocol: HTTPS
  • Hostname: *
  • Port: some port
  • Check “Enable HSTS”
• Destination
  • Protocol: HTTP
  • Hostname: localhost
  • Port: port exposed by your docker container
• Save

Step 2: Create Certificate

Control Panel > Security > Certificate > Add

• Add a new certificate > Next
• Enter a “Description”
• Get a certificate from Let’s Encrypt
• Domain name: your-syno.synology.me
• Email: your email

You can reuse the same certificate for multiple Docker containers.

Step 3: Use Certificate

Control Panel > Security > Certificate > Settings

• Service: As defined in Step 1 Source Hostname:Port
  • ex: *:some port
• Certificate: Select the Certificate created in Step 2

https://your-syno.synology.me:some_port should now work!

This configuration is written to /etc/nginx/sites-enabled/server.ReverseProxy.conf
